“ACTIO
TM
” – Full chassis with oscillation • Articulated
• 4WD quadtrack
• Reversibility RGS
TM
Diesel direct injection with counter rotating weight system
Stage 3A
4 - 16 Valves • Turbo
3319
64/87
2500
286,7/1850
Water
50/13.2
Synchronised 32 speed gear box: 16 forward and 16 reverse with synchronised inverter
Road approval up to 30 Km/h (19 mph)
Rear, independent and synchronised at 540/540E rpm with progressive
electrohydraulic engagement
Profile 1” 3/8 with 6 splines with facilitated engagement
Hydraulic control
Electrohydraulic control on the front
3 point hitch with adjustable quick release couplings and extensible arms
160/2320
2400/5291
Hydraulic with 2 pistons
Standard: hydraulic front and rear disk brakes in oil bath
Independent emergency and parking brake: band type on transmission
Suspended on Silent Block
3050/6725
3200/7055
Mach 4
Chassis
Engine
Type
Emissions Regulations
N° Cylinders
Displacement (CC)
Power kW/HP (97/68/CE)
Maximum engine revs
Torque max (Nm/revs)
Cooling
Tank Capacity (litres/gal):
Transmission
PTO
Shaft
Transmission clutch
Drive disengagement
Rear hydraulic lift
Operating Pressure (bar/psi)
Capacity (Kg/lbs)
Steering
Brakes
Platform
Weight
in order of speed:
With roll bar (Kg/lbs)
With cab (Kg/lbs)
TECHNICAL DATA:
Mach 4
Model
Standard Features
• Reversible control tower • Rear or front/rear differential
lock with electrohydraulic control • Hydraulic system with
2 separate hydraulic pumps • Adjustable steering wheel
• Adjustable lifting arms with quick release laterally moving
couplings • Adjustable, suspension seat with safety belt
• Foldable rear protection roll bar • 3 lever ancillary rear
hydraulic system • Rear adjustable height tow hitch • Front
tow hitch • Multifunctional digital instrument Km/h and
PTO • Battery • Battery isolation switch • Electrical power
point • Safety starting device on the inverter and PTO
• Predisposition for rear balancing ballast • Couple of pads
for rear tracks
Optional Features
• StarLight cab with air conditioning system and window
on the roof, suspended on Silent Blocks; activated carbon
filter on request • Hydraulic system controlled by “JPM”
Proportional Joystick with 11 hydraulic outlets with quick
couplers • Six hydraulic outlets replicated at the front
with controlled continuous flow • Support with six front
ballast weights • Hydraulic vertical tie-rod with electro-
hydraulic control • Front power lift • Front PTO 1000 rpm
with electrohydraulic control • Pneumatic seat • Front
bullbar • Front lamp guards • Clean FIX™ > reverse flow fan
for constant cleaning of the radiator and of the front grille
of the bonnet • ESC > Electronic Speed Control: electronic
and automatic speed and engine rev control device
•
Grammer seat
•
Rear balancing ballast
•
Couple of pads for
rear and front tracks • Road approval up to 40 Km/h (25
mp/h)
