The new version of the Antonio Carraro isodiametric articulated reversible tractor, the result of years expertise in the segment of articulated tractors.
New tractor, new engine, new experience.
SRX Ergit R is the brand-new articulated, Tier 4 Final Kubota-powered Antonio Carraro tractor. With a new joystick, a new dashboard, enhanced ergonomics and the super AIR Cabin – class 4 pressurization, FOPS & ROPS certification – it inherits the fierce Antonio Carraro tradition in the articulated reversible tractors, yet adding innovative elements for a unique driving experience.
The cab is soundproofed and fitted with an air conditioning system. It offers the operator onboard 360° all round vision particularly over the equipment and the terrain around the tractor even when reversing and working between narrow rows. Two types: for the steering reversible with 6 uprights and for the articulated reversible with just 4 uprights. In this case the operator’s vision in all directions is enhanced thus optimising vision over equipment whilst working in a reverse drive direction even when working between very narrow-rowed crops. The electrical system has LED* lighting to guarantee visibility during night-time and in dark places, thus guaranteeing safety and quality of work. The compact cab is internally comfortable. Its streamlined profile and conical shape are designed to ease the tractor’s disengagement from narrow-rowed crops as well as on lateral slopes as its height is also contained.
On request, the new specialized Tora can come with a joystick and a mechanical draft and position control lift, as well as the REDCab, which is soundproofed, fitted with an air-conditioning system and is enhanced with many high level optional extras. The wide windscreen guarantees the operator excellent visibility in all directions, privileging visibility over the equipment and the space around the tractor, which can be appreciated above all in reverse drive when operating amongst very narrow-rowed crops. The LED work headlights also guarantee the right illumination at night and in dark places. The RedCab has a streamlined design and a conical shape to assist the tractor’s disengagement amongst rowed crops, even on lateral slopes. In the articulated version of the REDCab has 4 uprights and full glass doors and a wider opening. Access aboard the tractor and rear visibility are the main strong points of this solution.
ACTIO–Antonio Carraro oscillating chassis: Ideal weight distribution, stability in slopes, Full adaptability to the soil, wide ground clearance;
ENGINE – 4 cyl 16V Kubota 3769 cc Tier 4 Final 75hp: Larger oil sump, low noise levels, low consumption, low vibration, efficiency with little heat production, low emissions.
TRANSMISSION - Max speed up to 25 mph, disengageable 4WD, optimized hydraulic circuit (oil only when required; more efficient, more comfortable, more silent, more economic).
Silent PTO optimized for working above 100 hp;
New optional working range: optimizes the engine torque when a low PTO regime is required.
AIR Cab – The only class-4-pressurized, FOPS available on a reversible articulated tractor.
- FOPS (falling objects protection) & ROPS (rollover protection) certification;
- Costant Class 4 pressurization;
- Acoustic and thermal insulation;
- LED lighting (8 lights);
- New silent block – More driving space, Perceived sound level inferior to 80dba*.
Damping standard – Pitch and swing damping system, active when the hydraulic lift is up. Available with standard hydraulic system and draft and position control.
Joystick – new ergonomics, more room for the feet.
Cruisecontrol – standard (double speed memory).
*inside the cab
With its 41,73 in. minimum width, SRX 7900 R is designed to work in vineyards and orchards with a minimum steering radius and the lowest possible compaction.
The weight distribution, optimized for attached devices, reduces the soil sinking within the rows and avoids root damage.
The reducers setup allows a good level of ground clearance despite the low profile, even with wide tyres. DESIGN
Tier 4 Final engines – because of the addition of DPA filters for reducing emissions – are bulkier; Nevertheless, both rollbar and cab versions of SRX 7900 R maintain the same dimensions and visibility of its predecessors.
SRX 7900 R offers top visibility, ergonomics, beauty and functionality thanks also to the curved-glass windscreen, doors and rear window.
Antonio Carraro S.p.A. is directly committed to the continuous development and improvement of its website, with an in-house team in charge of graphics, content and coordination.
ANTONIO CARRARO SPA Via Caltana, 24 - 35011 CAMPODARSEGO PD - Italy
Iscritta nel registro delle Imprese di Padova in data 19.02.1996 REA 126503 del 26.02.1976
Capitale Sociale in EURO deliberato-sottoscritto-versato 2.157.265,55
Sistema di amministrazione e controllo - CONSIGLIO DI AMMINISTRAZIONE
AC Full Chassis with Oscillation - cast iron full chassis hosting the tractor's transmission. with a central articulated joint which allows a longitudinal oscillation up to 15°; this system allows the tractor to keep up with the soil's sinuosity ensuring constant traction and grip.
RGS™ Rev-Guide System, is the AC reversible driving system on a rotating turret which inverts the driving direction in just a few seconds in order to work efficiently with towed or frontal equipment. Simply turn the seat/steering wheel/dash/pedal assembly 180° for an identical, but reverse, driving direction. MORE
The wheelbase, the limited external width and the articulated frame make the tractor very agile between crop rows. The smooth and sensitive hydroguide steering wheel assures precise maneuvering on steep slopes, in crossways movements, in bottlenecks, among crop rows and in car parks.
| Stability at all times
The Damping system, which is fitted as standard equipment and, when activated, compensates for stresses transmitted from the mounted implements, thereby increasing comfort while protecting both driver and machine from possible harm.
ESC (ERGIT R)ESC / CRUISE CONTROL (ERGIT R)
Electronic and automatic speed and engine rev control device. It memorizes and modulates the tractor speed at the operator's discretion.
Air suspension with load display - reclining backrest - lumbar support.
EXG Extended Warranty
As a proof of its reliability, Antonio Carraro offers, in addition to its two-year standard warranty, an extension of warranty coverage up to three or four years, called EXG Maximum Protection. [read]
Tubular steel guard protecting the bodywork; integrates the third-point for the front lift.
The AIR cab offers maximum level operative comfort and safety. The tractor and cab’s volumetric profile is harmonious and streamlined in order to grant agility and ease of movement in tight spaces and dense vegetation. To guarantee a perfect working climate there is the efficient heating and ventilation system with an integrated air-conditioning system.
