THE
17
SERIES
TECHNICAL DATA:
COUNTRY
ANTONIO CARRARO SPA
Via Caltana, 24
35011 Campodarsego Padova ITALY
antoniocarraro.com
COD. 4 7318 118
- 07/2012
The description and illustrations in this brochure are provided simply for information purposes; they are not binding and may be varied at any time without notice
Chassis
Engine
Type
Laws regarding emissions
Cylinders
Displacement (cc)
Output kW/HP (97/68/CE)
Max engine rpm
Max. torque (Nm/rpm)
Cooling system
Fuel tank capacity (l.)
Transmission
PTO
Shaft
Rear hydraulic lift
Capacity (Kg)
Operating Pressure (bar)
Steering
Brakes
Tyres:
Front
Rear
Min. ext. width (mm)
Ground clearance (mm)
Weight
in order of speed (Kg)
Dimensions
Standard Features
Optional Features
ACTIO
TM
– Full chassis with oscillation • Steering wheels • Four wheel drive
Diesel direct injection
Stage 3A
3
1642
28/38
3000
111/1200
Water
21
12-speed gearbox: 8 forward and 4 reverse speeds
Independent, with multi-plate clutch in oil bath, standard speed 540 rpm
and synchronised at all gear speeds
ASAE profil 1” 3/8 with 6 splines
Rear with 3-point linkage and position control - Cat. 1
140
850
Hydraulic
Rear-axle and parking brakes - Steering brakes
7.50-16
7.50-16
260/70 R16 29x12.50-15 Garden
300/70 R20 9.50-20
300/70 R20 36x13.50-15 Garden
1200
1145
1200
1435
260
260
235
260
1150
Wheelbase: 1240
Front overhang: 925
Lenght: 2865
Height: 2005
Front and rear differential lock • Front drive diesngagement • Adjustable
padded seat • Safety Belts • Tow hitch • Auxiliary hydraulic system consisting of
1 double acting distributor with floating position and 2 rear quick couplings
• Foldable safety roll bar • Horn • Lights • Power socket • Braking and turning
indicators • Series ofcontrol lights • Tachometer/revolution counter
• Safety starting switch
Hydraulic power lift with draft and position control • Rear revolving working
light • Wheel ballasts
4400
