Chassis
Engine
Type
Emissions Regulations
N° Cylinders
Displacement (CC)
Power kW/HP (97/68/CE)
Maximum engine revs
Torque max (Nm/revs)
Cooling
Tank Capacity (litres/gal):
Transmission
PTO
Shaft
Rear hydraulic lift
Operating Pressure (bar/psi)
Capacity (Kg/lbs)
Steering
Brakes
Tyres
: Front
Rear
Min. ext. width (mm/in)
Ground clearance (mm/in)
Weight
in order of speed (Kg/lbs)
Standard Features
Optional Features
ACTIO
TM
-Full chassis with oscillation • Steering wheels
4 equal wheel drive
4 unequal wheel drive
Diesel direct injection with counter rotating weight system
Stage 3A
Stage 3A
Stage 3A
4
3 Turbo
3 Turbo
2190
2082
2082
35/48
41,2/56
41,2/56
2800
2600
2600
140/1680
195/1400
195/1400
Water
Water
Water
40/10.56
40/10.56
40/10.56
Gear box with 24 speeds: 12 forward, 12 reverse with inverter
Independent, with mechanic control, standard speed 540 rpm and synchronized at all gear speeds
Profile 1” 3/8 with 6 splines with facilitated engagement
3-points hitch Cat. 1
140/2030
140/2030
140/2030
2100/4630
2100/4630
1900/4188
Hydraulic with 2 double acting pistons with “Load Sensing” system
Mechanic rear oil bath disc brakes - Steering brakes
Rear axle and parking handbrake with control lever operating the main device
7.50-16 8.25-16 7.50-18 250/80-18 280/70 R18 300/80-15.3
JonaF
:
8.25x16
300/80-15.3 280/70 R18
7.50-16 8.25-16 7.50-18 250/80-18 280/70 R18 300/80-15.3
280/85 R20 360/70 R20 12.4 R20
1235/48.6 1265/49.8 1280/50.4 1305/51.4 1380/54.3 1395/54.9
1325/52.1 1465/57.6 1340/52.7
253/9.96 263/10.3 286/11.2 286/11.2 275/10.8 304/11.9
263/10.3
304/11.9
272/10.7
1600/3527
1620/3571
1750/3858
Front and rear differential locks, front foot lock, with mechanic control • Adjustable suspension seat
• Safety belts • Rear adjustable height tow hitch • Front tow hitch • Foldable protection roll bar
• Adjustable wheel rims • Horn • Hydraulic system with 1 single-acting manifold • Lights, braking and turning
indicators • Unipolar socket and 7 way trailer socket • Series of control lights • Tachometer/revolution counter
• Safety starting switch
Hydraulic power lift with draft and position control • PTO at 540E and 1000 rpm • Rear revolving working
light • 4 types of ancillary hydraulic systems with single-acting and double-acting manifolds (up to 5 rear quick
couplers) • Wheel ballasts • Cast iron wheel flanges for 20’’ rear wheels (only for JonaF)
TECHNICAL DATA:
Tigrone
ANTONIO CARRARO SPA
Via Caltana, 24 35011
Campodarsego Padova ITALY
antoniocarraro.com
COD. 4 7318 136 -
01/2014
The description and illustrations in this brochure are provided simply for information purposes; they are not binding and may be varied at any time without notice.
5800 Jona
6400 Jona
6400 JonaF
665/26.2
1743÷1794* / 68.2÷70.6*
TIGRONE JonaF
TIGRONE Jona
1385/54.5
1095/43.1
3145/123.8
2062÷2113 / 81.2÷83.1
2070÷2113 / 81.5÷83.1
985/38.7
1463/57.6
790/31.1
3238/127.4
1751÷1794* / 68.9÷70.6*
*Height calculated with the operator of average
height sitting (mm/in 1750/68.9)
