4
3
2
1
4
3
2
1
4
3
2
1
4
3
2
1
Km/h
0
40
32 24 18 14 10 987654321
Miles/h
Km/h
Miles/h 0
24
20 16 12 1086 5 4 3 2 1
Chassis
Engine
Type
Transmission
PTO
Shaft
Transmission clutch
Drive disengagement
Rear hydraulic lift
Operating Pressure (bar/psi)
Steering
Brakes
Platform
Tyres
Weight
in order of speed:
Standard Features
Optional
“ACTIO
TM
” – Full chassis with oscillation • 2 rear tracks and 2 front steering wheels
• Reversibility RGS
TM
Diesel direct injection with counter rotating weight system
Emissions Regulations: Stage 3A
N° Cylinders: 4 - 16 Valves • Turbo
Displacement (CC): 3319
Power kW/HP (97/68/CE): 64/87
Maximum engine revs: 2500
Torque max (Nm/revs): 286,7/1850
Cooling: Water
Tank Capacity (litres): with roll bar 60 - with cab 50
Synchronised 32 speed gear box: 16 forward and 16 reverse with synchronised inverter
Road approval 35 Km/h
Rear, independent and Synchronised at 540/540E rpm with progressive electrohydraulic engagement
Profile 1” 3/8 with 6 splines with facilitated engagement
Hydraulic control
Electrohydraulic control on the front
With 3 point hitch- Capacity (Kg): 2300
160
Hydraulic with 2 pistons
Standard: hydraulic front and rear disk brakes in oil bath,
Independent emergency and parking brake: band type on transmission
Suspended on Silent Block
11.2 R20
with roll bar: 2950
with cab: 3100
• Reversible control tower • Rear or front/rear differential lock with electrohydraulic control • Hydraulic system with
2 separate hydraulic pumps • Adjustable steering wheel • Adjustable lifting arms with quick release laterally moving
couplings • Front foldable protection roll bar with slow-dampened spring • 2 lever ancillary rear hydraulic system
• Rear adjustable height tow hitch • Front tow hitch • Multifunctional digital instrument Km/h and PTO • Battery •
Battery isolation switch • Electrical power point • Safety starting device on the inverter and PTO • Accelerator with
suspended pedal
• StarLight cab with air conditioning system and window on the roof, suspended on Silent Blocks; activated carbon
filter on request • Electrohydraulic
e-DRIVE
transmission with reverse shuttle under the steering wheel and range
shift • ESC > Electronic Speed Control: electronic and automatic speed and engine rev control device • Lift and
hydraulic quick couplers controlled by “Proportional” Joystick • UNIFLEX hydraulic suspension • Hydraulic power lift
with electronic draft and position control with DAMPING • Support with six front ballast weights • Hydraulic third
hitch and vertical tie-rod with electro-hydraulic control • Up to five types of hydraulic system with a maximum of
11 hydraulic quick couplers • Rear balancing ballast • Pneumatic seat • Slider tow hitch • Front bullbar • Front lamp
guards • Clean FIX™ > reverse flow fan for constant cleaning of the radiator and of the front grille of the bonnet
TECHNICAL DATA:
Mach 2
ANTONIO CARRARO SPA
Via Caltana, 24 35011
Campodarsego Padova ITALY
antoniocarraro.com
COD. 4 7318 148
- 01/2014
The description and illustrations in this brochure are provided simply for information purposes; they are not binding and may be varied at any time without notice
845÷895
2420
1465
1190
3500÷3550
2195
1475
DIMENSIONS
SPEED
335
