The dimensions are calculated in mm/in with 7.50-16 tyres
*
Height with collapsed roll-bar
Chassis
Engine
Type
Cylinders
Displacement (cc)
Output kW/HP (97/68/CE)
Max engine rpm
Max. torque (Nm/rpm)
Cooling system
Fuel tank capacity (l./gal)
Transmission
Power take-off
Shaft:
Hydraulic power lift
Working pressure (bar)
Capacity (Kg/lbs)
Steering
Brakes
Tyres
Type
Min. ext. width (mm/in)
Ground clearance (mm/in)
Steerig radius
ext. (mm/in)
Weight
in working trim (kg/lbs)
Standard equipment
Electrical system
and instruments
Optionals
The descriptions and illustrations published herein are of a merely informative nature and are not binding and may be changed or modified without prior notice.
3200
ACTIO
TM
– Full chassis with oscillation • Steerable wheels • Four equal wheel drive
Diesel indirect injection
3
1116
19,2/26
3000
67,8/2000
Water
215/5,54
12-speed mechanical gearbox: 8 forward and 4 reverse speeds
Standard at 540 rpm and synchronised with all gearbox speeds
ASAE profil 1” 3/8 with 6 splines
Rear with 3-point hitch (cat. 1)
140
950/2094
Hydraulic
Rear-axle and parking brakes
7.50-16
6.50-16
7.5L-15
29x12.50-15 STG 29x12.50-15 GARDEN
1155/45.4
1070/42.1
1110/43.7
1375/54.1
1375/54.1
330/13.0
316/12.4
310/12.2
305/12.0
305/12.0
2900/114.1
2900/114.1
2900/114.1
2900/114.1
2900/114.1
1000/2205
Front and rear independent differential lock • Adjustable, sprung seat • Safety belts • Foldable safety roll bar
• Multiple-hole draw-bar • Tow hook
Horn • Lights • Power socket • Braking and turning indicators • Series of control lights • Tachometer/revolution
counter • Safety starting switch
Rear revolving working light • Wheel ballasts • Single acting hydraulic outlet with rear quick coupling
• Mudguards widening for wide wheels
THE
15
SERIES
Tigre 3200
A*
1630
B
680
C
1100
D
860
E
2640
F
960÷1030
G
2010÷2075
F
E
B
C
D
G
A
*
