50% 50%
The ACTIO™ system consists of a powerful, steel section which forms an integral part of the axle,
which houses both a front and rear transmission and has an oscillating joint which allows for
longitudinal oscillation of a good 15 degrees.
Thanks to the ACTIO ™ system, the tractor acts as a single unit, made up of two parts with the same mass and
dimension which oscillate independently of each
other following the contours and different gradients of
the terrain
, thereby maintaining constant stability and perfect grip.
Its overhanging engine is positioned on the fore-carriage: this allows the total weight of the tractor to be
redistributed - 60% of its weight on the front axle and 40% on the rear one.
Ideal balance
that becomes
almost perfect when rear equipment is fitted:
50% on the front and 50% on the rear
.
Furthermore, the ACTIO™ system provides for the use of
four large equal wheel drive
. In this way there
is even better grip and the engine is able to ground all of its power with consequent advantages in terms of
productivity and safety.
The wheels are available in a vast range of diameters and with different tyre
profiles
in order to satisfy all requirements and to create optimum configuration according to the type of ground
and usage.
Full Chassis with Oscillation ACTIO™:
perfect balance between agility and grip
ADVANTAGES OF THE ACTIO SYSTEM™:
• Perfect distribution of weight
= maximum grip, less wear and tear on tyres.
• Central, lower drive position
= the prolonged use of the tractor is less stressful with respect to more traditional
tractors; greater protection for the operator.
• Transmission inside the chassis
= good ground clearance, lower centre of gravity; maximum stability even with
transversal movement on steep slopes and in cases of loss of grip the tractor’s lateral transfer avoids rollovers.
• Doubling of the total mass of the tractor and ample lateral oscillation
= the two parts of the tractor
counterbalance each other thereby maintaining maximum adherence of the tyres to the ground.
• Possibility of being fitted with 4 large equal wheels
= better traction and more balanced weight distribution.
