“ACTIO
TM
” – Full chassis with oscillation • Reversibility RGS
TM
• Steering wheels
• 4 equal wheel drive • Front and rear final drive
Diesel direct injection with counter rotating weight system
Emissions Regulations: Stage 3A
N° Cylinders: 4 - 16 Valves • Turbo
Displacement (CC): 3319
Power kW/HP (97/68/CE): 64/87
Maximum engine revs: 2500
Torque max (Nm/revs): 286,7/1850
Cooling: Water
Tank Capacity (litres/gal): 60/15.85
Hydrostatic – Continual variation of forward speeds in both drive direction from 0>40 Km/h
with a mechanical selector of the 4 speed variator – Electrohydraulic reverser under the
steering wheel – ESC (Electronic Speed Control) Electronic and automatic speed and engine rev
control device – “Automotive Eco-Power” device
Rear, independent and synchronized at 540/540E rpm with progressive
electrohydraulic engagement
Profile 1” 3/8 with 6 splines with facilitated engagement
Hydraulic control
Electrohydraulic control on the front
Draft and position control with 3 point hitch
160/2320
2400/5291
Hydraulic with 2 pistons
Standard: hydraulic front and rear disk brakes in oil bath, rear steering brakes
Independent emergency and parking brake: band type on transmission
Suspended on Silent Block
2205÷2315 / 4861÷5104
2275÷2385 / 5015÷5258
2365÷2475 / 5214÷5456
TRH 9800
Chassis
Engine
Type
Transmission
PTO
Shaft
Transmission clutch
Drive disengagement
Rear hydraulic lift
Operating Pressure (bar/psi)
Capacity (Kg/lbs)
Steering
Brakes
Platform
Weight
in order of speed:
With roll bar (Kg/lbs)
With chassis (Kg/lbs)
With cab (Kg/lbs)
Standard Features
• Reversible driving position with servo-assisted reversibility
• Rear or front/rear differential lock with electrohydraulic
control • Hydraulic system with 2 separate hydraulic pumps
• Adjustable steering wheel • Lifting arms with quick release
couplings • Adjustable, suspension seat with safety belt
• Foldable protection roll bar • Adjustable wheel rims
• 3 lever ancillary rear hydraulic system • Rear adjustable
height tow hitch • Front tow hitch • Multifunctional digital
instrument Km/h and PTO • Battery • Electrical power point
• Safety starting device on the inverter and PTO
Optional
• Star Light cab with air conditioning system and window on
the roof, suspended on Silent Blocks • EasyStar safety chassis
with 6 uprights, fitted on Silent-block, with roof and left rear
view mirror, (optional) front and rear windschields complete
with wipers and right rear view mirror • Lift and hydraulic
quick couplers controlled by “ON/OFF” or “Proportional”
Joystick • Lift controlled by “ON/OFF” Joystick with hydraulic
suspension (2+2 cylinders) • Support with six front ballast
weights • Hydraulic third hitch and vertical tie-rod with
electro-hydraulic control • Front power lift • Gearbox with
PTO 540-1000 rpm • Up to five types of front hydraulic
system with a maximum of 11 hydraulic quick couplers
• Adjustable lifting arms with quick release couplings
• Pneumatic seat • Slider tow hitch • Pair of front/rear
ballasts • Cast iron wheel flanges for 20’’ rear wheels • Front
bullbar • Front lamp guards • Clean FIX™ > reverse flow fan
for constant cleaning of the radiator and of the front grille of
the bonnet
TECHNICAL DATA:
TRH
Model
