Chassis
Engine
Type
Transmission
PTO
Shaft
Transmission clutch
Drive disengagement
Rear hydraulic lift
Operating Pressure (bar)
Steering
Brakes
Platform
Tyres
Min. ext. width (mm)
Ground clearance (mm)
Weight
in order of speed (Kg):
Standard Features
Optional Features
“ACTIO
TM
” – Full chassis with oscillation • Reversibility RGS
TM
• Steering wheels
• 4 equal wheel drive • Front and rear final drive
Diesel direct injection with counter rotating weight system
Emissions Regulations: Stage 3A
N° Cylinders: 3 Turbo
Displacement (CC): 2082
Power kW/HP (97/68/CE): 41,2/56
Maximum engine revs: 2600
Torque max (Nm/revs): 195/1400
Cooling: Water
Tank Capacity (litres): 50
Synchronised 32 speed gear box: 16 forward and 16 reverse with synchronised inverter
Rear, independent and synchronised at 540/540E rpm with progressive electrohydraulic engagement
Profile 1” 3/8 with 6 splines with facilitated engagement
Hydraulic control, without the need for adjustment
Electrohydraulic control on the front
With 3 point hitch cat. 1and 2 - Capacity (Kg): 2100
160
Hydraulic with 2 pistons
Standard: hydraulic front and rear disk brakes in oil bath, rear steering brakes
Independent emergency and parking brake: band type on transmission
Suspended on Silent Block
250/80 R18 300/80-15.3 320/65 R18 300/70 R20 280/70 R18 340/65 R18
31x15.50-15
1380
1445
1460
1410
1420
1485
1690
275
275
275
310
275
285
240
With roll bar: 2000 With chassis: 2110 With cab: 2190
• Reversible control tower • Rear or front/rear differential lock with electrohydraulic control • Fixed lifting arms
• Adjustable, suspension seat with safety belt • Protection roll bar • Adjustable wheel rims • Auxiliary rear hydraulic
remotes with 1 double acting distributor with floating position, 1 oil reflow (total 3 quick couplings) • Rear
adjustable height tow hitch • Front tow hitch • Multifunctional digital instrument • Battery • Electrical power point
• Safety starting device on the inverter and PTO
• Star Light cab with air conditioning system and window on the roof, suspended on Silent Blocks • EasyStar
safety chassis with 6 uprights, fitted on Silent-block, with roof and left rear view mirror, (optional) front and rear
windscreens complete with wipers and right rear view mirror • Lift and hydraulic quick couplers controlled by
double speed “ON/OFF” Joystick • Rear power lift with suspension (2+2 pistons) • Hydraulic power lift with draft
and position control • Front power lift • Hydraulic third hitch and vertical tie-rod • Adjustable lifting arms with
quick release couplings • Pneumatic seat • Slider tow hitch • Pair of front/rear ballasts • Cast iron wheel flanges for
20’’ rear wheels • Front bullbar
TECHNICAL DATA:
TRX 6400
The description and illustrations in this brochure are provided simply for information purposes; they are not binding and may be varied at any time without notice.
3295÷3445
720÷870
1595
980
1795÷1860*
*Height calculated with the operator of average
height sitting (cm 175)
StarLight cab
EasyStar chassis
2195÷2260
2100÷2170
2000÷2070
DIMENSIONS
ANTONIO CARRARO SPA
Via Caltana, 24
35011 Campodarsego Padova ITALY
antoniocarraro.com
COD. 4 7318 137
- 01/2014
