Chassis
Engine
Type
Transmission
PTO
Shaft
Transmission clutch
Drive disengagement
Rear hydraulic lift
Operating Pressure (bar)
Steering
Brakes
Platform
Tyres
Min. ext. width (mm)
Ground clearance (mm)
Weight
in order of speed (Kg):
Standard Features
Optional Features
“ACTIO
TM
” – Full chassis with oscillation • Steering wheels • 4 equal wheel drive • Front and rear final drive
TX
model
>
single-direction
/ TRX
model
>
with
Rev-Guide System RGS™
Diesel direct injection with counter rotating weight system
Emissions Regulations: Stage 3A
N° Cylinders: 4 - 16 Valves
Displacement (CC): 3319
Power kW/HP (97/68/CE): 52/71
Maximum engine revs: 2500
Torque max (Nm/revs): 236/1600
Cooling: Water
Tank Capacity (litres): 60 (with roll bar) / 50 (with frame and cab)
Synchronised 32 speed gear box: 16 forward and 16 reverse with synchronised inverter
Rear, independent and synchronised at 540/540E rpm with progressive electrohydraulic engagement
Profile 1” 3/8 with 6 splines with facilitated engagement
Mechanic control
Electrohydraulic control on the front
With 3 point hitch cat. 1 - Capacity (Kg): 2150
140
Hydraulic with 2 pistons
Standard: hydraulic front and rear disk brakes in oil bath, rear steering brakes
Independent emergency and parking brake: band type on transmission
Suspended on Silent Block
250/80-18 300/80-15.3 320/65 R18 300/70 R20 280/70 R18 320/70 R20 400/55-17.5 31x15.50-15 280/85 R20 340/65 R18
1380
1445
1460
1410
1420
1460
1690
1690
1415
1485
286
298
286
320
275
330
282
242
341
300
TX
with roll bar: 2070÷2170 with frame: 2120÷2220
with cab: 2210÷2310
TRX
with roll bar: 2080÷2180 with frame: 2130÷2230
with cab: 2220÷2320
• Reversible control tower (for TRX) • Rear or front/rear differential lock with electrohydraulic control • Lift arms
fix type • Adjustable, suspension seat with safety belt • Protection roll bar • Adjustable wheel rims • Auxiliary rear
hydraulic remotes with 1 double acting distributor with floating position, 1 oil reflow (total 3 quick couplings)
• Rear adjustable height tow hitch • Front tow hitch • Multifunctional digital instrument • Battery • Electrical power
point • Safety starting device on the inverter and PTO
• Star Light cab with air conditioning system and window on the roof, suspended on Silent Blocks • EasyStar
safety frame with 6 uprights, fitted on Silent-block, with roof and left rear view mirror, (optional) front and rear
windscreens complete with wipers and right rear view mirror • Lift and hydraulic quick couplers controlled by
double speed “ON/OFF” Joystick (for TRX) • Rear power lift with suspension (for TRX) • Front power lift (for TRX)
• Hydraulic power lift with draft and position control • Hydraulic third hitch and vertical tie-rod (for TRX) • Adjustable
lifting arms with quick release couplings • Slider tow hitch • Pair of front/rear ballasts • Cast iron wheel flanges for
20’’ rear wheels • 6 front ballast weights • Front bullbar • Front lamp guards
TECHNICAL DATA:
TX / TRX
ANTONIO CARRARO SPA
Via Caltana, 24
35011 Campodarsego Padova ITALY
antoniocarraro.com
The description and illustrations in this brochure are provided simply for information purposes; they are not binding and may be varied at any time without notice.
TX 7800"S" / TRX 7800"S"
TX 7800
TRX 7800
A
708
708
B
1495
1495
C
1190
1190
D
3393
3393
E*
1775÷1875
1775÷1875
F
2272÷2371
2272÷2371
G
2132÷2227
2132÷2227
H
2032÷2127
2032÷2127
F
D
A
B
C
G
E*
*
Height calculated with the operator of average height sitting (cm 175)
H
StarLight cab
EasyStar frame
COD. 4 7318 142 - 06/2012
DIMENSIONS:
TX / TRX
