TRX 7800 S
Power
71 HP
Engine
Yanmar - Tier3A - 4 Cyl - 16V - 3319 CC
Transmission
16+16 synchronized reverser
Weight (KG)
2080 (rollbar) - 2130 (EasyStar cab) - 2220 (Starlight cab)
Capacity (KG)
2150

TRX Ergit S - Reversible - Isodiametric steering tractor


TRX ERGIT S - TAYLOR-MADE TRACTOR

TRX 7800 Serie S
 (71 CV) is a professional tractor with a mature, certified technology. The modern design, alligned with the AC top-range tractors' family feeling, is functional to a better practicity on-field. The choice of direct injection, worldwide admired engines is a promise of low consumption and top performances.

TRX 7800 S is designed for agricultural tasks on flat or sloping grounds. The perfect weight distribution and the 4-wheel drive offer great grip, constant traction, nearly no soil compaction. Moreover for the soil safety, the front traction can be deactivated at any time.

REVERSIBLE

TRX 7800 S
 is an isodiametric tractor with RGS™ Rev-Guide System , an integrated system which allows an 180° rotation of the driver's station, in order to use naturally frontal devices (forklift, blade, mulcher, snowblower). Its great versatility makes it fit both in agriculture and in urban and green maintenance.


+++Available only for specific markets+++

Plus

ACTIO™

RGS™

Comfort

Transmission - 16+16

Pneumatic seat

Bullbar

Vertical tie-rod and hydraulic thirdpoint

Starlight Cab

Easystar Cab

Joystick - TRX

Joystick JPM™

Air conditioner

Cabs

StarLight

CLOSED CAB

StarLight is the Antonio Carraro closed cab assembled on Silent Block anti-vibrating device. It is equipped with front/rear windscreens, total-glass doors, double sunroof with sunscreens and portholes with view on wheels and devices, thanks to which it offers on-board brightness and total visibility.
The smooth design is functional to its performance through side-sloping rows or underfoliage. StarLight's compactness allows agility in the most narrow spaces with neither fruit nor flowers damage.
The soundproof clothing of the driver's station grants acoustic comfort.
The main controls are in ergonomical position.
The ventilation system  features a rapid front windscreen defogging system. he incoming air is cleaned by a large filter, with an available activated carbon filter. The air-conditioning is achieved by a powerful system running on ecological coolant, which also refreshes the cabin air using a low rev motor. The heating system utilizes a powerful heat exchanger which is most exceptional even in the coldest weather. The roof can be opened to lift the electric fans for quick maintenance intervention. StarLight offers also two rear and two front lights – all adjustable. Two adjustable rearview mirrors, foldable plate holder, glovebox, electrical setup and speakers for stereo system, are other details of the onboard comfort of Starlight. As every Antonio Carraro cab, Starlight is certified as anti-capsizing device.

EasyStar

MULTI-PURPOSE MODULAR FRAME
EasyStar 6-post cab is a must-have device to protect the operator from sun, bad weather and dust.
Starting from the standard configuration (6-post frame and sunroof), one can add front and rear windscreens and the doors set.
Covered by Antonio Carraro warranty, EasyStar is safer than many untested, uncertified products at the same cost.
In addition to its unmatched quality, its design is pleasant and perfectly suitable to the chosen tractor.

ACTIO™

AC Full Chassis with Oscillation - cast iron full chassis hosting the tractor's transmission. with a central articulated joint which allows a longitudinal oscillation up to 15°; this system allows the tractor to keep up with the soil's sinuosity ensuring constant traction and grip.
[read

RGS™

RGS™ Rev-Guide System, is the AC reversible driving system on a rotating turret which inverts the driving direction in just a few seconds in order to work efficiently with towed or frontal equipment. Simply turn the seat/steering wheel/dash/pedal assembly 180° for an identical, but reverse, driving direction.
MORE

Comfort

Thanks to the ACTIO™ Chassis, the driving position coincides with the center of oscillation of the tractor. Sideways jerking and stress are very limited and operator fatigue is reduced, even after many hours. The on-board instrumentation is elegant, functional and intuitive: backlit anti-reflection screen for nighttime use; “on-off” information system; digital tachometer and PTO rev counter; and electro-hydraulic pushbutton controls.

Transmission - 16+16

Synchronized transmission gearbox with 32 speeds, 16 fwd +16 rev, and synchronized shuttle reverser; PTO 540/540e independent and ground speed with progressive electrohydraulic engagement; Start inhibit switch on shuttle reverser and PTO selector; Electrohydraulic front/rear or only rear differential lock; Electrohydraulic disengagement control for front drive wheels; Hydraulic clutch.

Pneumatic seat

Pneumatic suspension seat with height regulation and automatic driver-weight adjustment (from 50 kg ti 130 kg).

Bullbar

Tubular steel guard protecting the bodywork; integrates the third-point for the front lift.

Optional

Vertical tie-rod and hydraulic thirdpoint

Optimizes the positioning and inclination of the equipment.

Optional

Starlight Cab

StarLight is the Antonio Carraro closed cab mounted on Silent Blocks. With the large windows and portholes giving a view of the wheels and implement, it is very luminous and provides total visibility. It has opening front and rear windscreens, total-glass doors and double sunroof with sunscreens.
MORE

Optional

Easystar Cab

EasyStar 6-post cab is a must-have device to protect the operator from sun, bad weather and dust. Starting from the standard configuration (6-post frame and sunroof), one can add front and rear windscreens and the doors set.

Joystick - TRX

Available on demand several hydraulic settings controlled by on-off joystick (electro-proportional available on TRX 10900) ; draft and position control available; hydraulic suspension available on TRX 7800 S and TRX 9900.

Joystick JPM™

JPM™ Proportional Joystick - Available on demand electro-proportional hydraulic system controlled by joystick; 11 quick couplings; available also forcing pump for front hydraulic engine.

Optional

Air conditioner

The soundproof cab offers also an automatically controlled air conditioning system.
Optional
