A new "wide track" version with low centre of gravity is the latest addition to the Tony family of isodiametric tractors with hybrid mechanical-hydrostatic transmission with electronic control. The special configuration of this version renders it ideal for working across slopes (haymaking in particular). Available with the optional Extracomfort cab suspended on Silent Block mountings, it offers a particularly comfortable and roomy driving position. The engine is a 4-cylinder turbo Kubota with electronic Common Rail injection that delivers 98 hp and is Stage 3B compliant. The 540/540E and groundspeed PTO features electrohydraulic control with progressive engagement.
The Tony transmission allows operators to customize their own working method, optimizing results and simplifying procedures. Diagnostic software constantly monitors tractor data to ensure optimal performance in all working conditions. The transmission uses SIM (Shift In Motion) technology with 4 electronically-controlled speed ranges, which can be engaged when the tractor is both stationary and moving, with 3 acceleration modes for each range and 3 for each range in Automotive mode.
INTELLIGENT TRACTOR AC > The ITAC operating system allows the operator to interface with tractor to complete the task in hand. The TMC (Tractor Management Control) function offers various possibilities for working in automatic mode, including: Automotive Cruise Control, which maintains a constant ground Wspeed for an optimal engine rpm; Intellifix, which ensures maximum torque for the preset rpm when working with a load on theW PTO; Automotive, which ensures acceleration is proportional to engine speed.
* For 10900 models, check your local dealership for availability.
Antonio Carraro S.p.A. is directly committed to the continuous development and improvement of its website, with an in-house team in charge of graphics, content and coordination.
ANTONIO CARRARO SPA Via Caltana, 24 - 35011 CAMPODARSEGO PD - Italy
Iscritta nel registro delle Imprese di Padova in data 19.02.1996 REA 126503 del 26.02.1976
Capitale Sociale in EURO deliberato-sottoscritto-versato 2.157.265,55
Sistema di amministrazione e controllo - CONSIGLIO DI AMMINISTRAZIONE
AC Full Chassis with Oscillation - cast iron full chassis hosting the tractor's transmission. with a central articulated joint which allows a longitudinal oscillation up to 15°; this system allows the tractor to keep up with the soil's sinuosity ensuring constant traction and grip. MORE
RGS™ Rev-Guide System, is the AC reversible driving system on a rotating turret which inverts the driving direction in just a few seconds in order to work efficiently with towed or frontal equipment. Simply turn the seat/steering wheel/dash/pedal assembly 180° for an identical, but reverse, driving direction. MORE
The short wheelbase and tight steering radius make the tractor extremely agile in crop rows. To further reduce the turning radius, the steering* brakes can be utilized, while accentuating the steering effect obtained thanks to the double-acting constant velocity joints.
Hydrostatic transmission with hydraulic control; Mechanical selector with 3 speed range: low/normal/high; Continuous speed variator in both forward and reverse from 0-6, 0-12, 0-28 km/h; Independent PTO with 2 speed: 540 and 1000 rpm; Front and rear differential lock; Disengaging drive wheels on rear axle; Speed-fix control.
The Tony transmission is an ultra-compact hybrid-hydrostaticmechanical transmission, which optimises the tractor’s performance by lifting it to maximum operational efficiency. It offers the operator maximum yield and precision during operational tasks as well as extraordinary facility of use; the electronic inverter, for example... [read more]
Tubular steel guard protecting the bodywork; integrates the third-point for the front lift.
Extra comfort Cab
TTR Extra Comfortcab is a homologated, original AC product. Its sober, elegant design provides a total-glass structure in order to offer total visibility and on-board brightness. TTR Ergit 100 in its standard version offers an open cab with front and rear windscreens. Often, however, the operator demands more comfort within a closed, air-conditioned cab.
