TR 7600 Infinity
75 HP
Kohler - Turbo Stage 3B - 4 cyl - 16V - 2482 cc
Weight (KG)
2205÷2315 rollbar- 2365÷2475 cab
Capacity (KG)
TR 7600 Infinity
Reversibie with hybrid transmission

TR 7600 Infinity is the isodiametric tractor by Antonio Carraro with hybrid mechanical/hydrostatic transmission, designed for specialized agriculture, road maintenance and greencare. It can also be used for vineyards and orchards, haymaking, earthmoving, road cleaning, banks and slopes.
The 74 hp (2482 cc), 4 cylinders engine, propels the tractor up to 40 km/h, assisted by the hydrostatic transmissione Infinity in both directions of travel, with two mechanical ranges - 3 speeds each, shiftable while in action with no loss of traction or power interruption.
TR 7600 Infinity is available in rollbar, open cab with windscreen or StarLight cab, also with hydraulic system controlled by on-off or electro-proportional joystick. Available also on demand the Uniflex hydraulic suspension.


Antonio Carraro | Plus | ACTIO


AC Full Chassis with Oscillation - cast iron full chassis hosting the tractor's transmission. with a central articulated joint which allows a longitudinal oscillation up to 15°; this system allows the tractor to keep up with the soil's sinuosity ensuring constant traction and grip.


RGS™ Rev-Guide System, is the AC reversible driving system on a rotating turret which inverts the driving direction in just a few seconds in order to work efficiently with towed or frontal equipment. Simply turn the seat/steering wheel/dash/pedal assembly 180° for an identical, but reverse, driving direction.
Antonio Carraro | steering tractors

Steering wheels

The short wheelbase and tight steering radius make the tractor extremely agile in crop rows. To further reduce the turning radius, the steering* brakes can be utilized, while accentuating the steering effect obtained thanks to the double-acting constant velocity joints.

Antonio Carraro | Comfort | Driver's seat


Thanks to the ACTIO™ Chassis, the driving position coincides with the center of oscillation of the tractor. Sideways jerking and stress are very limited and operator fatigue is reduced, even after many hours. The on-board instrumentation is elegant, functional and intuitive: backlit anti-reflection screen for nighttime use; “on-off” information system; digital tachometer and PTO rev counter; and electro-hydraulic pushbutton controls.

UNIFLEX® Suspension

The UNIFLEX suspension with coaxial cylinders maximises its efficiency thanks to a reduced number of friction points. Its innovative concept allows the equipment to follow and adapt itself to the contours of the ground, keeping the ground pressure constant thus benefitting speed and work precision.
Antonio Carraro | Plus | Grammer seat with pneumatic suspension


Air suspension with load display - reclining backrest - lumbar support.
Antonio Carraro | Front Protection | Bullbar


Tubular steel guard protecting the bodywork; integrates the third-point for the front lift.
Antonio Carraro | Plus | Vertical tie-rod and hydraulic thirdpoint

Vertical tie-rod and hydraulic thirdpoint

Optimizes the positioning and inclination of the equipment.
Antonio Carraro | Radiator cleaning | Cleanfix

ACS - Auto-cleaning system

Reverse flow fan that assures the constant cleaning and efficienc of the radiator and of the front grille of the bonnet.


More braking, more safety - Additional braking system, perfect for slope-parking. By activating the handbrake, with a subsequent pressure on the brake pedals all 4 oil disk brakes are blocked. The system works with the tractor engine both running or off.
Antonio Carraro | Options | Froltlift

Front lift

Available on demand the front lifting system for the use frontal implements.
Antonio Carraro | Optional | Air conditioner

Air conditioner

The soundproof cab offers also an automatically controlled air conditioning system.


StarLight Cab


StarLight is the Antonio Carraro closed cab assembled on Silent Block anti-vibrating device. It is equipped with front/rear windscreens, total-glass doors, double sunroof with sunscreens and portholes with view on wheels and devices, thanks to which it offers on-board brightness and total visibility.
The smooth design is functional to its performance through side-sloping rows or underfoliage. StarLight's compactness allows agility in the most narrow spaces with neither fruit nor flowers damage.
The soundproof clothing of the driver's station grants acoustic comfort.
The main controls are in ergonomical position.
The ventilation system  features a rapid front windscreen defogging system. he incoming air is cleaned by a large filter, with an available activated carbon filter. The air-conditioning is achieved by a powerful system running on ecological coolant, which also refreshes the cabin air using a low rev motor. The heating system utilizes a powerful heat exchanger which is most exceptional even in the coldest weather. The roof can be opened to lift the electric fans for quick maintenance intervention. StarLight offers also two rear and two front lights – all adjustable. Two adjustable rearview mirrors, foldable plate holder, glovebox, electrical setup and speakers for stereo system, are other details of the onboard comfort of Starlight. As every Antonio Carraro cab, Starlight is certified as anti-capsizing device.

EasyStar Cab

EasyStar 6-post cab is a must-have device to protect the operator from sun, bad weather and dust.
Starting from the standard configuration (6-post frame and sunroof), one can add front and rear windscreens and the doors set.
Covered by Antonio Carraro warranty, EasyStar is safer than many untested, uncertified products at the same cost.
In addition to its unmatched quality, its design is pleasant and perfectly suitable to the chosen tractor.

The UNIFLEX* suspension with electronic control allows for part of the weight of the equipment to be transferred to the tractor’s wheels. The reduction of specific ground pressure leads to numerous positive effects:
Lower compaction
Less resistance to pushing and pulling
Greater productivity
Lower fuel consumption
Greater grip
Greater stability
 The UNIFLEX suspension with coaxial cylinders maximises its efficiency thanks to a reduced number of friction points.  Its innovative concept allows the equipment to follow and adapt itself to the contours of the ground, keeping the ground pressure constant thus benefitting speed and work precision.

Infinity transmission

TR has two mechanical speed ranges (0-15 and 0-40 km/h), each offering three hydrostatic speeds, which can also be engaged while travelling without loss or traction or power interruption; all comfortably controlled using the joystick fitted as standard.

Tempomat / Cruise Control – Revolution and speed active independent control system. Both can be kept constant also in case of inconsistent stresses.
Eco – Consumption and noise reduction system that automatically takes the engine from the maximum revolution regime to the minimum required for maximum speed (40 km/h).
Advancement pedal – assisted braking also in case of slopes, with complete safe stop of the vehicle upon release of the accelerator, even when not using the brakes or the clutch.

ACS – Automatic Cleaning System, new self-cleaning radiator system .

PTO – 510-540E synchronized with progressive electro-hydraulic engagement, on demand 540-1000.
